| Place of Origin: | Fujian, China |
|---|---|
| Brand Name: | HI-CREATE |
| Certification: | CE |
| Model Number: | HC-DMP |
| Minimum Order Quantity: | 1 Set |
| Price: | $80,000.00 - $200,000.00 / Set |
| Packaging Details: | adult diaper packing machinery is packing by wooden case |
| Delivery Time: | 60 days |
| Payment Terms: | L/C, T/T |
| Supply Ability: | 1 Set/Sets per Month |
| Condition: | New | Application: | Commodity |
|---|---|---|---|
| Packaging Type: | Bags, Stand-up Pouch | Packaging Material: | Plastic |
| Automatic Grade: | Automatic | Driven Type: | Mechanical |
| Voltage: | 380V 50Hz | Power: | 25KW |
| Weight: | 5.5Ton | Dimension(L*W*H): | 5.4*4.1*2.1m |
| Working Speed: | Up To 450-550 Pieces/min And 20-30 Bags/min | Finished Product Rate: | >=98% |
| Product Thickness Dimensions: | 8-16mm | Number Of Products Per Row: | 10-45pcs/row |
| Finished Bags Dimensions, Single Row: | Min. 120*100*120 Mm, Max. 480*140*280 Mm(W*H*L) | Finished Bags Dimension, Double Rows: | Min. 120*100*280 Mm, Max. 480*140*560 Mm(W*H*L) |
| Pre-made Bags Dimensions: | Min. 220*220 Mm, Max. 580*650 Mm(W*L) | Pre-made Bags(PE)thickness: | 40-80μm |
| Air Supply: | 0.65-0.85Mpa | Product Keywords: | Adult Diaper Packing Machinery |
| After-sales Service Provided: | Engineers Available To Service Machinery Overseas | Port: | Xiamen |
| Highlight: | HC-DMP Adult Diaper Machine,5.5Ton Adult Diaper Machine,25KW adult diaper packing machine |
||
Main Features:
1. Fully servo driven,Servo motor management by electronic CAM
2. Two levels compression, suitable for varied size of packing
3. Modular structure design
4. Quick Auto/ Manual packing size switching
5. Force restrict protection, stable running
6. Stacking and packing 2 in 1, less land occupied
7. Suitable for single row or double rows packing
Main Technical parameters:
|
Model |
HC-DMP |
|
Working speed |
Up to 450-550 pieces/min and 20-30 bags/min |
|
Finished product rate |
≥98% |
|
Product thickness dimensions |
8-16mm |
|
Number of products per row |
10-45pcs/row |
|
Finished bags dimensions, single row |
Min. 120*100*120 mm, Max. 480*140*280 mm(W*H*L) |
|
Finished bags dimension, double rows |
Min. 120*100*280 mm, Max. 480*140*560 mm(W*H*L) |
|
Pre-made bags dimensions |
Min. 220*220 mm, Max. 580*650 mm(W*L) |
|
Pre-made bags(PE)thickness |
40-80μm |
|
General dimensions |
5.4*4.1*2.1m, 8.2*4.1*2.1 m(including material receiver)(L*W*H) |
|
Total Weight |
5.5Ton |
|
Electrical Power consumption |
25KVA |
|
Air Supply |
0.65-0.85Mpa |
|
Standard process direction |
Left-hand process. Right-hand process direction available upon request. |
Packing & Shipping:
Our Company & Factory:
HI-CREATE is manufacturer for disposable hygiene products machinery development, design and producing, mainly in production line for baby diaper , sanitary napkin, waistband diaper , training pant(pull up) diaper, adult diaper , and a series of household paper, disposable products processing equipment for toilet paper, tissue paper, and napkin paper.
Our Office:
Our Services:
Our Visitors:
Our Certificates:
Our Exhibition:
Customer Message:
Customer’s Photos:
FAQ:
1. Are you a manufacturer or trading company?
We are a manufacturer with our factories, more than 10-year experience in this industry.
2. Where is your factory?
Our factory locates in Xidong Industrial Zone, Huian Town, Quanzhou, Fujian, China.
3. How long is the turnaround time?
It takes about 30-60 working days to finish. And it depends on different products and customized requirements.
4. How long is your delivery time?
15-60 days after order being confirmed. Detailed delivery date should be decided according to production season and order quantity.
5. Can your machine do customization for our products?
We could do some customization size to fit your products size according to your requirement.
